Power Supply Controller AC 110-240V to DC 12V for Door Access Control System & Video Intercom Entry

$ 15.99

In stock

AUTENS power supply controller is small, easy to install and easy to use. The voltage ranges from 100V-240V to normal use, suitable for all countries of the world.
Power supply controller is a transformer which provides stable output voltage for access controller, lock, and exit button.
Set NC / NO outputs, can control various types of electric locks. Based delay control circuit, lock time can be in 0-15 seconds.
UPC: 749715919169

Compare
SKU: SVE00021 Categories: ,

Features:

It is a door access control power supply
Compatible with world voltage, lightweight, convenient transportation, small disturbance
NC / NO outputs, can control various types of electric locks
Reduce the load of access controller, save wiring to reduce the hidden trouble
Wide input voltage range, steady and precise
Automatic protection function:overload/ over voltage/ short circuit
It can set time lapse control circuit and unlocking time can be in 0-15 seconds(it is arbitrarily adjustable)
Provide very stable and reliable output in a various applications such as lock control/ controller control/ exit button/ RFID reader etc.
Protection mechanism: power may be temporarily disconnected or the fuse auto insured

Specification:

Input Voltage: 110-240VAC (Worldwide voltage)
Input Frequency: 50-60Hz
Output Voltage: 12VDC/3A
Power: 36W
Load: 0.5% Typical
Output Stability: 0.5% Typical
Hold Time: Full Load Typically 20ms
Operating Temperature: -4℉~149℉
Adjustable Locking Delay: 0~15sec
Dimensions: 4.72Lx3.74Wx1.50H(in)
Net Weight: 315g

Package:

1 x Power Supply
1 x User manual (English)

Note: Opening time must set to 0 second when connecting with electric controlled lock. Otherwise electric bolt lock would be Burned Down.
